Workshop Manual Bar Bender UB 100

Description Specifications Compare Accessories Downloads

Description

Workshop Manual Bar Bender - UB-100

100 x 5mm

Overview

This versatile workshop bar bender is designed for both cold and hot bending of a wide range of steel profiles, making it ideal for fabrication, metalworking and small workshop projects. Whether working with flat, round, square, or angle steel, this machine provides precise, repeatable bends with adjustable stops and a robust mounting system for stability. Its user-friendly design ensures safe and reliable operation, allowing you to bend steel efficiently to the exact angles and radii required.

Features

COLD BENDING - Flat 100x5mm, Square 16x16mm, Round Ø18mm, Angle Steel 60x8mm (only with pre-notching)
HOT BENDING - Flat 100x10mm, Square 20x20mm, Round Ø20mm, Angle Steel 100x10mm (only with pre-notching)
Mount to work bench with 4 mounting holes for sturdy operation
Adjustable bending stop with angle scale up to 120°
Adjustable material length stop for repeatability
Eccentric quick action cam lever material clamp
Wide supporting face ensuring safe and reliable operation
Bending angle of various radius by changing and/or turning around die plate

Includes

Additional Bending Plates

Specifications

Compare Product Range

Specifications

ORDER CODE	B043
MODEL	UB-100
(mm)Flat Bar Capacity - Mild Steel	100 x 5 60 x 6 25 x 7
(mm)Square Bar Capacity - Mild Steel	16 x 16
(mm)Round Bar Capacity - Mild Steel	Ø18
(mm)Bending Lever Length	690
(kg)Nett Weight	30
