Showing Products On Special....

49 Products Found


AL-320G
Bench Lathe
320 x 600mm
(240V)
HAFCO METALMASTER
Code:
L141
$2,460.00 ex GST
$2,829.00 inc GST
L141

AL-320G Bench Lathe 320 x 600mm
(240V)

CODEL141
ModelAL-320G
Digital Readout System FittedOptional
Quick Change Toolpost FittedOptional
Tool Height To Suit12mm
Distance Between Centres600mm
Swing Over Bed320mm
Swing Over Cross-slide210mm
Centre Height160mm
Spindle Bore38mm
Spindle Nose TypeFixed
Bed Width160mm
Headstock Taper5MT
HAFCO METALMASTER
$2,460.00 ex GST
$2,829.00 inc GST

CL-60B
Centre Lathe
460 x 1500mm - 80mm Bore
Includes Digital Readout, Quick Change Toolpost & Taper Turning Attachment
(415V)
HAFCO METALMASTER
Code:
L605D
Please Call
L605D

CL-60B Centre Lathe 460 x 1500mm - 80mm Bore
Includes Digital Readout, Quick Change Toolpost & Taper Turning Attachment(415V)

CODEL605D
ModelCL-60B
Digital Readout System FittedYes
Quick Change Toolpost FittedYes
Taper Turning AttachmentYes
Tool Height To Suit25mm
Distance Between Centres1500mm
Swing Over Bed460mm
Swing Over Cross-slide270mm
Swing In Gap690mm
Centre Height230mm
Spindle Bore80mm
Camlock Spindle SizeD1-8
HAFCO METALMASTER
Please Call

TM-2680G
Centre Lathe
660 x 2000mm - 115mm Bore
Includes Digital Readout
(415V)
HAFCO METALMASTER
Code:
L639D
$34,500.00 ex GST
$39,675.00 inc GST
L639D

TM-2680G Centre Lathe 660 x 2000mm - 115mm Bore
Includes Digital Readout(415V)

CODEL639D
ModelTM-2680G
Digital Readout System FittedYes
Quick Change Toolpost FittedOptional
Tool Height To Suit30mm
Distance Between Centres2000mm
Swing Over Bed660mm
Swing Over Cross-slide438mm
Swing In Gap890mm
Centre Height330mm
Spindle Bore115mm
Camlock Spindle SizeD1-11
Bed Width400mm
HAFCO METALMASTER
$34,500.00 ex GST
$39,675.00 inc GST

AL-280P
Lathe Mill Drill Combination
400 x 409mm
(240V)
HAFCO METALMASTER
Code:
L159
$1,700.00 ex GST
$1,955.00 inc GST
L159

AL-280P Lathe Mill Drill Combination 400 x 409mm
(240V)

CODEL159
ModelAL-280P
Lathe SpecificationsLathe Specifications
Tool Height To Suit12mm
Distance Between Centres409mm
Swing Over Bed400mm
Swing Over Cross Slide300mm
Centre Height200mm
Spindle Bore20mm
Spindle Nose TypeFixed
Bed Width140mm
Tailstock Taper3MT
Cross Slide Travel115mm
HAFCO METALMASTER
$1,700.00 ex GST
$1,955.00 inc GST

GHD-20A
Geared Head Drill
31.5mm Drilling Capacity
3MT
(415V)
HAFCO METALMASTER
Code:
D134
$3,100.00 ex GST
$3,565.00 inc GST
D134

GHD-20A Geared Head Drill 31.5mm Drilling Capacity
3MT(415V)

CODED134
ModelGHD-20A
Drilling Capacity31.5mm
Spindle Taper3MT
Spindle Travel140mm
Throat Depth220mm
Quill Diameter60mm
Column Diameter100mm
Spindle To Table630mm
Spindle To Base1070mm
Table TypeRound
Table Sizeø390mm
T-Slot Size14mm
HAFCO METALMASTER
$3,100.00 ex GST
$3,565.00 inc GST

RAD-900
Radial Arm Drill
38mm Drilling Capacity
(415V)
HAFCO METALMASTER
Code:
D165
$11,995.00 ex GST
$13,794.25 inc GST
D165

RAD-900 Radial Arm Drill 38mm Drilling Capacity
(415V)

CODED165
ModelRAD-900
Drill Capacity38mm
Threading CapacityM20
Spindle Taper4MT
Spindle Travel200mm
Quill Diameter70mm
Spindle To Column (min-max)290-920mm
Spindle To Box Table (max)785mm
Spindle To Base (max)1110mm
Table TypeSquare
Box Table Size (LxWxH)550 x 405 x 315mm
T-slot Size20mm
HAFCO METALMASTER
$11,995.00 ex GST
$13,794.25 inc GST

BM-65VE
Turret Milling Machine
(X) 925mm (Y) 420mm (Z) 480mm
Includes Digital Readout
(415V)
HAFCO METALMASTER
Code:
M629D
$16,950.00 ex GST
$19,492.50 inc GST
M629D

BM-65VE Turret Milling Machine (X) 925mm (Y) 420mm (Z) 480mm
Includes Digital Readout(415V)

CODEM629D
ModelBM-65VE
Digital Readout3-Axis Digital Readout
TypeVertical
Table Size1500 x 300mm
Spindle Taper - VerticalNT40
Longitudinal Travel (X-Axis)925mm
Cross Travel (Y-Axis)420mm
Vertical Travel (Z-Axis)480mm
Type of SlidesSquare (Y & Z)
Ram Travel485mm
Spindle to Table530mm
Quill Travel / Diameter155mm / 105mm
HAFCO METALMASTER
$16,950.00 ex GST
$19,492.50 inc GST

BM-90HV
Turret Milling Machine - Horizontal - Vertical
(X) 1120mm (Y) 520mm (Z) 440mm
Includes Digital Readout
(415V)
HAFCO METALMASTER
Code:
M633D
$35,950.00 ex GST
$41,342.50 inc GST
M633D

BM-90HV Turret Milling Machine - Horizontal - Vertical (X) 1120mm (Y) 520mm (Z) 440mm
Includes Digital Readout (415V)

CODEM633D
ModelBM-90HV
Digital Readout3-Axis Digital Readout
TypeVertical & Horizontal
Table Size1470 x 370mm
Spindle Taper - VerticalNT40
Spindle Taper - HorizontalNT40
Longitudinal Travel (X-Axis)1120mm
Cross Travel (Y-Axis)520mm
Vertical Travel (Z-Axis)440mm
Type of SlidesSquare (Y & Z)
Ram Travel600mm
Spindle to Table505mm
HAFCO METALMASTER
$35,950.00 ex GST
$41,342.50 inc GST

SG-820H
Hydraulic Surface Grinder
450 x 220mm
(415V)
HAFCO METALMASTER
Code:
G220
$9,400.00 ex GST
$10,810.00 inc GST
G220

SG-820H Hydraulic Surface Grinder 450 x 220mm
(415V)

CODEG220
ModelSG-820H
Chuck Size400 x 200mm
Max. Longitudinal Table Traverse450mm
Max. Cross Table Traverse220mm
Max. Spindle To Table490mm
Wheel Diameter200mm
Vertical Increment Graduations0.01mm
Vertical Graduations Per Rev.1.25mm
Spindle Motor1100W 1.5HP
Spindle Motor Voltage415V
Weight (nett)750kg
HAFCO METALMASTER
$9,400.00 ex GST
$10,810.00 inc GST
